The CSB-100KG load cell from South Korea's Curiotec (CURIOSITY TECHNOLOGY COMPANY) is a high-performance weighing and force-measuring component.
- Model: CSB-100KG
- Brand: Curiotec (South Korea)
- Type: S-type load cell
- Capacity: 100KG
- Full Environmental Protection
- Anodized aluminum (20 kgf - 250 kgf)
- Nickel-plated steel (500 kgf - 2 tf)
- Material
- Cable: Braided shield 4-wire round cable with PVC jacket
The working principle of the CSB-100KG sensor is based on the resistance strain effect. When an external force acts on the sensor, the elastic element inside it will deform, resulting in a change in resistance value. This change is detected by circuits such as the Wheatstone bridge and converted into a voltage or current signal for output. The output electrical signal is proportional to the weight borne. After calibration, high-precision weight measurement can be achieved.
Regular inspection and maintenance of the sensor are key to ensuring its long-term stable operation. It is necessary to keep the sensor and its surrounding environment clean to avoid the impact of pollutants such as dust and moisture on the sensor. At the same time, it is necessary to regularly check whether the connecting cables and circuits of the sensor are normal, and whether the sensor is damaged or worn.
Here is the detailed information of the CSB-100KG Load Cell. As a home of imported sensors, Modern Hero Technologies(shenzhen)CO.,LTD has perfect technical services and pre - sales and after - sales support. If necessary, please contact us.
